LANCE™ GHRM LED Hazardous Location Area Light – Conveyor Lighting
Share
LANCE™ GHRM LED Hazardous Location Area Light – Conveyor Lighting
The LANCE™ GHRM Series Conveyor Lighting is designed for open-pit mining conveyor systems, delivering reliable and efficient illumination for conveyor belts, transfer points, maintenance areas, and access walkways. With an output range of 6,000 to 9,600 lumens, the GHRM Series provides balanced lighting performance for low to medium installation heights. Its rugged construction is suited for demanding outdoor mining environments, offering dependable performance in conditions involving dust, moisture, vibration, and temperature variations.
Features
- Easy Installation. Single barrel nut and hinge design, one-hand operation for quick and easy installation
- Lightweight & Compact. 3.5kg fixture weight only, design for low mounting heights and confined spaces.
- High Efficacy. Delivers up to 160 lm/W reducing energy costs by up to 75% over conventional lamps.
- Retrofit Friendly. Universal mounting accessories minimizes the SKUs and maximizes the flexibility.
- Build To Last. Copper-free aluminum housing and impact resistant lens sealed from the outside environment provides ingress protection against water and dust.
- Terminal blocks fitted as standard for faster installation
| Rated Power | 40W / 60W |
|---|---|
| Input Voltage | AC100-277V, 347-480V |
| Input Frequency | 50/60Hz |
| Driver Efficiency | ≥ 90% |
| Lumen Output | 6,000lm / 9,600lm |
| Luminous Efficacy | 160Lm/W |
| Beam Angle | T1 / T3 / 110° |
| CCT | Amber / 2700K / 3000K / 4000K / 5000K |
| CRI | Ra>70 |
| Operating Temperature | -40°C~+65°C |
| Lens Material | Glass / PC / Drop lens |
| Mounting Options | Pendant / Ceiling / Wall mount / Stanchion / U-Bracket |
| Cable Entries | 3/4”NPT, 1”NPT, 1-1/4”NPT, 1-1/2”NPT |
| Net Weight | 3.5kg |
| Dimming | Standard 1 – 10VDC |
Catalog Number
See Build Your Own on Spec/Install/IES Sheet
Spec – Install – IES – LANCE™ GHRM
